Tadano TM-ZR500XL-4 Cargo Crane Operator Manual

A Tadano TM-ZR500XL-4 is a cargo crane that loads and unloads on a real job, lifting freight on and off trucks and decks. A used crane often shows up without the book in the cab, and that's when a relief operator or the new owner goes looking for the operator manual. This one is written for the TM-ZR500XL-4 and gives you the operating rules in one place.

What this manual helps you do

• Check the machine before operation using the Before Operation section.
• Set the outriggers by following the Rules for Operation (Outriggers).
• Follow the general operating rules, plus the rules for weather, power lines and radio waves.
• Plan road moves with the Rules for Traveling on Roads and close out the shift with After Operation.
• Inspect the crane and read the warning labels, with their locations and contents, using the Rules for Inspection and Maintenance.

Who this is for

A fleet manager uses it to put the operating rules and daily checks on file for every crane that goes out. An operator taking over a used TM-ZR500XL-4 uses it to learn the controls, the setup sequence and the safety rules before the first lift.

FAQ

Q: What do I receive and how is it organised?

A: You get the full set of 4 manuals as 10 PDF files, 611 pages in total, in English. The main manual is publication TM-ZR500XL-4-O(2)(U)-3E at 302 pages, alongside publication TM-ZR500XL-4-O(2)(U)-2E (149 pages), Manual 2 (5 pages) and publication OD3(U)-1E (155 pages).

Q: Which machine does it fit?

A: It is for the Tadano TM-ZR500XL-4 cargo crane, serial number EH9935 and up as printed on the main manual cover. Check the serial plate on your crane against that number.

Q: How does it fit my job?

A: The main manual carries a Safety Section and the Operation and Maintenance Manual Main Body, so you can hand it to a new operator and point to the exact rules for setup, weather, travel and daily inspection.

Put the set on file, load it into the cab or the office, and give every operator the same rules to work from.

Click here to view the preview (PDF)

Does this manual fit your machine?

The serial number shown is the one printed on the manual cover. Check the model and serial number on your machine's data plate before ordering.
