Caterpillar EP16TCB Forklift Service and Operator Manual (99759-6T110)

Yes, this is the right manual set for a Cat EP16TCB electric counterbalanced forklift within the listed serial ranges. On the floor or yard, this truck handles pallet movement, loading, and general plant work. I'd reach for this set when diagnosing faults, checking service data, or repairing the truck by the book, especially where alarm codes and controller settings may be audited.

What this manual helps you do

• Trace wiring, switches, sensors, and electrical fault circuits.
• Diagnose alarm codes and traction motor or controller problems.
• Check service intervals, adjustments, and operating procedures.
• Follow repair procedures for the drive unit, brakes, steering, hydraulics, mast, and forks.
• Verify controller parameters and troubleshoot charging or truck operation issues.

Who this is for

This suits a warehouse maintenance technician, plant maintenance team, dealer technician, independent forklift shop, or rental fleet mechanic working on EP16TCB trucks. It is a workshop service reference with the operator handbook as the companion publication in the same set.

FAQ

Q: What do I receive, and how is it organised?

A: You receive 42 PDF files covering 504 pages, split by section and supplied as a two-publication set, not a single booklet. The PDFs support printing, zooming, text search, and copying text.

Q: Which trucks does it fit?

A: It covers Cat EP16TCB models with serial coverage 215E00001-up, 264E00001-up, 216E00001-up, 265E00001-up, 288E00001-up, 266E00001-up, 283E00001-up, and 267E00001-up. That gives you the correct reference for the listed EP16TCB variants.

Q: How does it fit the job I'm doing?

A: Use it for planned maintenance, fault diagnosis, electrical testing, controller work, and mechanical repairs. It gives a technician the procedures and service information needed to work on the truck in the shop or field.

For an EP16TCB in these serial groups, this is the service and operator set to use for maintenance, troubleshooting, and repair.

Models covered by this manual

Caterpillar publication 99759-6T110 is the factory service and operator manual for the EP16TCB. The same publication covers 15 further forklift models: EP13TCB, EP13TCB(J), EP15TCB, EP15TCB(J), EP16TBCB, EP16TBCB(J), EP16TCB(J), EP18TBCB, EP18TBCB(J), EP18TCB, EP18TCB(J), EP20TBCB and 3 more. The cover also lists EP16/18/20TCB(J), EP16/18/20TBCB(J), EP13TCB(J)-20TCB(J),, EP16TBCB(J)-20TBCB(J). Check the model and serial number on your data plate before ordering.

Table of Contents:

• Sit on the forklift truck seat and turn on the key switch
• Push Lift lever forward to lower the forks to the ground
• Do not make a sudden start and brake or turn
• Do not make a sudden valve lever operation at a
• Do not run sideways or handle on an incline
• When the red lamp of battery capacity indicator
• Check electrolyte every week and replenish water
• Be sure to use the prescribed fuses
• W x 50 Ω or
• W x 20 Ω
• MPa, with
• SERVICE
• ELECTRIC
• MOTOR
• N or less
• L per side
• N·m of torque to the preload measured
