Caterpillar EP13TCB Forklift Service and Operator Manual (99759-6T110)

An EP13TCB is an electric counterbalanced Cat forklift used to move and stack pallets around a warehouse or plant. I reach for a service manual when a truck needs electrical fault tracing, hydraulic work, mast repair, or a proper adjustment instead of guesswork. This set is aimed at the technician doing the repair, with the operator material included for day-to-day reference.

What this manual helps you do

• Trace wiring, switches, traction circuits, and controller faults.
• Diagnose drive, braking, steering, hydraulic, and mast problems.
• Follow procedures for traction motor, controller, axle, brake, and hydraulic repairs.
• Adjust and verify steering, brakes, mast components, and operating systems.
• Troubleshoot the EP13TCB using service data and workshop test procedures.

Who this is for

This suits a warehouse maintenance tech, plant maintenance crew, dealer technician, independent forklift shop, or rental fleet mechanic working on Cat electric trucks. It is workshop documentation for the forklift trade, and the companion chassis or operator volume is also available when a job calls for it.

FAQ

Q: What do I receive, and how is it organized?

A: You receive two Cat publications in a set, delivered as 25 PDF files split by section, with 331 pages total. The PDFs have a real text layer, so you can search and copy text, then print or enlarge pages on screen.

Q: Which trucks and serials does it cover?

A: It covers EP13TCB(J), EP15TCB(J), EP16/18/20TCB(J), EP16/18/20TBCB(J), EP13TCB(J)-20TCB(J), and EP16TBCB(J)-20TBCB(J), including the listed E-series serial groups beginning 215E, 264E, 216E, 265E, 288E, 266E, 283E, and 267E.

Q: How does it fit the job?

A: Use it for in-house service, fault finding, adjustment, and repair work on the electric truck. It gives the shop a working reference instead of relying on trial and error.

If your truck is one of those EP13TCB-family models, yes, this is the right service set to put on the shop computer.

Models covered by this manual

Caterpillar publication 99759-6T110 is the factory service and operator manual for the EP13TCB. The same publication covers 15 further forklift models: EP13TCB(J), EP15TCB, EP15TCB(J), EP16TBCB, EP16TBCB(J), EP16TCB, EP16TCB(J), EP18TBCB, EP18TBCB(J), EP18TCB, EP18TCB(J), EP20TBCB and 3 more. The cover also lists EP16/18/20TCB(J), EP16/18/20TBCB(J), EP13TCB(J)-20TCB(J),, EP16TBCB(J)-20TBCB(J). Check the model and serial number on your data plate before ordering.

Table of Contents:

• Sit on the forklift truck seat and turn on the key switch
• Push Lift lever forward to lower the forks to the ground
• Do not make a sudden start and brake or turn
• Do not make a sudden valve lever operation at a
• Do not run sideways or handle on an incline
• When the red lamp of battery capacity indicator
• Check electrolyte every week and replenish water
• Be sure to use the prescribed fuses
• W x 50 Ω or
• W x 20 Ω
• MPa, with
• SERVICE
• ELECTRIC
• MOTOR
• N or less
• L per side
• N·m of torque to the preload measured
