ZF-AS Tronic Transmission Service Manual

A transmission like the ZF-AS Tronic sits between the engine and the driveline on a crane carrier or heavy machine, and it decides whether the unit moves or sits in the yard. When it faults or needs work, the person with the spanner wants workshop procedures, not guesses. This service manual is the repair document for that job.

What this manual helps you do

• Follow the instructions for carrying out repairs before you open up the transmission.
• Check tightening torques in the manual's own tables instead of relying on memory.
• Diagnose faults using the diagnosis section and the test device and diagnosis tool chapters.
• Troubleshoot the ZF-Intarder with its own diagnosis tool section.
• Replace components by working through the component replacement section, with maintenance steps alongside.

Who this is for

A rental fleet mechanic or crane service technician who repairs units in-house and wants the procedure on the bench. It also suits an independent repair shop or plant maintenance team that takes on ZF-AS Tronic work and needs a documented reference for each job.

FAQ

Q: What do I receive and how is it organised?

A: You get 1 PDF file, 70 pages, in English. It opens with an overview of amendments, a preface and important information, then moves through repairs, torques, tools, maintenance, diagnosis, component replacement and an annex.

Q: Which transmission does it fit?

A: It is written for the ZF-AS Tronic, and the title wording is "ZF-AS Tronic Trucks Repair Manual", publication number 1327 751 101a. Match that number and name to your unit and you're set.

Q: How does it fit my job?

A: If you're diagnosing a fault, replacing a component or doing scheduled maintenance, the sections follow that order of work. It also includes a chapter on changing from DIN to ISO standard codes, which helps when reading older references.

Keep it on the shop computer or tablet next to the transmission, and the repair, the torque check and the diagnosis can all be done from one document.

Click here to view the preview (PDF)
