Tadano GR-900XL-2 Rough Terrain Crane Service Manual

A rough terrain crane like the GR-900XL-2 works on uneven, unprepared job sites, setting up on outriggers and lifting with a telescopic boom. When one of these comes into the shop for a repair, the person with the wrench needs workshop procedures, not guesswork. That means fleet mechanics, independent shops and dealer techs who are pulling, rebuilding or adjusting components and want the steps and checks in front of them.

What this manual helps you do

• Troubleshoot the hydraulic power generating system before you start replacing pumps and valves.
• Rebuild outrigger, boom elevating and boom telescoping components by following the removal and assembly procedures.
• Adjust the swing, winch and steering systems to the settings the manual gives.
• Diagnose faults in the control system, safety system and electric system.
• Replace brake, suspension and driving power transmission parts with the procedure open beside you.

Who this is for

A crane service technician or rental fleet mechanic who is fixing machines in-house. It also suits an independent repair shop that picks up a used crane with no paperwork and needs to know how it goes together.

FAQ

Q: What do I receive and how is it organised?

A: You get one PDF file of 427 pages in English. The text can be searched and copied, and the manual is split by system, from hydraulic power generating through to suspension, with safety and foreword at the front and a revision history at the back.

Q: Which machine does it fit?

A: It is written for the Tadano GR-900XL-2, with serial number 547248 and up printed on the cover. The same manual also covers the GR-1000XL-2.

Q: How does it fit the job I'm doing?

A: If you're tracing a fault, rebuilding a component or setting something back to spec, you can search the system name or fault term and go straight to that section. Each system has its own section, so you open only what the job needs.

Open the PDF, search the system you're working on, and start the repair with the procedure in hand.

Click here to view the preview (PDF)

Does this manual fit your machine?

The serial number shown is the one printed on the manual cover. Check the model and serial number on your machine's data plate before ordering.

Models covered by this manual

This service manual is also used for one further Rough Terrain Crane model: GR-1000XL-2. Check the model and serial number on your data plate before ordering.
