Tadano TR-600XL-3 Rough Terrain Crane Service Manual

A rough terrain crane like the TR-600XL-3 works on soft, uneven ground where a truck crane can't get in. It sits on outriggers, swings a telescopic boom, and runs a winch for the lift. When one of those systems acts up, the person with the wrench needs the workshop book open on the bench. That's usually a shop fixing a machine in-house, or a tech looking at a used crane that arrived with no paperwork.

What this manual helps you do

• Troubleshoot faults in the hydraulic system, outrigger system and telescoping system with the manual's test and check procedures.
• Rebuild swing, elevating and winch components following the removal and disassembly steps.
• Diagnose electrical problems using the electric equipment section and the system diagrams.
• Adjust the steering system, brake system and suspension to the settings in the data, adjustments and checks section.
• Verify the safety devices and the AML after a repair, before the crane goes back to work.

Who this is for

Crane service technicians and rental fleet mechanics who repair their own machines. Also independent repair shops and dealer technicians who take on Tadano rough terrain cranes and want the procedures in front of them, not guesswork.

FAQ

Q: What do I receive and how is it organised?

A: You get 1 PDF file of 1,268 pages, in English. It is split into sections such as general cautions, hydraulic system, drive system, transmission system, electric equipment, MDT, options and system diagrams.

Q: Which machine does it fit?

A: It is the XL-3 Crane Service Manual for the Tadano TR-600XL-3. The same manual also covers the TR-300XL-3, TR-350XL-3 and TR-500XL-3.

Q: How does it fit the job I'm doing?

A: If you're pulling a component, setting adjustments or chasing a fault, a service manual like this is where you'd expect to find the procedure. The sections follow the crane's systems, so you can go straight to the one you're working on.

Keep it on the bench for your next teardown, adjustment or fault hunt on the TR-600XL-3.

Click here to view the preview (PDF)

Models covered by this manual

This service manual is also used for 3 further Rough Terrain Crane models: TR-300XL-3, TR-350XL-3, TR-500XL-3. Check the model and serial number on your data plate before ordering.

Table of Contents:

• GENERAL CAUTIONS
• HYDRAULIC SYSTEM
• OUTRIGGER SYSTEM
• SWING SYSTEM
• ELEVATING SYSTEM
• WINCH SYSTEM
• TELESCOPING SYSTEM
• SAFETY DEVICES
• AML
• CRANE CONTROLS
• ELECTRIC EQUIPMENT
• MDT
• DRIVE SYSTEM
• TRANSMISSION SYSTEM
• STEERING SYSTEM
• BRAKE SYSTEM
• SUSPENSION
• OPTIONS
• OPERATOR MANUAL
• DATA, ADJ. AND CHECKS
• SYSTEM DIAGRAMS
